Fader Wing Interaction With Eos Consoles
Eos will automatically recognize the fader wings and their configuration (2 x 10, 2 x 20) once they
are plugged into the console. The system will configure the faders according to the configuration in
fader wing configuration screen, for more information see{Fader Wing Config}, page 102. The
system will automatically configure the leftmost fader wing to start with fader page one. Any
subsequent rows or wings will then be configured in succession to represent the appropriate faders.
On fader wings, Latest-Takes-Precedence (LTP): any levels set on the console will override
settings on the wings. Your next move on the fader wing will override the console.
When 2x fader wings are attached to each other, the faders will populate continuously across the
attached array. The top row of all wings will be successive from one wing to the next. The bottom
row will start where the entire top row left off and then will also be successive from one wing to the
next.
Therefore, when fader wings are attached to each other:
LCD
The display at the center of the fader wing shows information about the faders.
For submasters the sub number, label, and current value (0-100%) of the fader are shown. When
the page is changed, the current value will display the necessary percentage the fader must be set
at to match the required level of the submaster.
For playbacks the cue list number will be shown preceded by an “L” {for example “L3” = cue list 3).
Beneath this the current pending cue is displayed in an oval shape.
For Grandmasters, a “GM” is displayed and the current output percentage is shown (100% -
blackout).
Fader Wing Paging
The fader wing is paged using the [Fader Page] button on the Eos console. Fader pages are
delineated in 20 fader increments. If you advance to the next fader page, your entire fader wing
array will advance by a total of 20 faders.
To change the fader page of a fader wing:
Step 1: Press and hold the [Fader Page] button on the Eos console. The LCD on the fader
wing will display the available pages beneath the fader bump buttons.
Step 2: Press the bump button corresponding to the page you wish to display on the fader
wing. The fader wing will display those faders after your selection is made.
2x10 2x20 2x10
Top Row Faders
Bottom Row Faders
1 - 10
41 - 50
31 - 40
71 - 80
11 thru 30
51 thru 70
To Next Page
