E Radio Focus Remote (RFR) 349

iRFR

The iRFR is a software application that runs on an Apple iPhone® or iPod Touch. The application

can be downloaded from the Apple Application Store, search for iRFR. The iRFR offers the same

functionality of the RFR. A closed wireless network is needed.

For additional information on the iRFR, including setup, please visit the iRFR Documentation Wiki
