Cb Offset
Varies the Source Cb. 45
C-Bit Control
Enables the user to set the C-Bit Control. 79
CC CDP Output
Enables CDP packet processing on the output. 133
CC CDP Write Line
Selects the output line number to insert CDP packets 133
CC Line 21 Output
Enable
Enables closed caption handling for SD outputs. 133
CC1 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
CC2 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
CC3 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
CC4 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
Centre Width
Controls the width of front centre sound. 102
Clear Duration Control
The Clear Duration defines the amount of time that the IntelliGain
system must be corrected to before a correction SNMP trap is sent
to VistaLINK
®
.
126
Compander Attack Time
The Compander Attack Time control defines how quickly the
compander reacts to an increase in the input loudness
118
Compander Profile
The compander profiles are used to define the dynamic range
control of the compander
123
Compander Release
Time
The Compander Release Time control defines how quickly the
compander reacts to a decrease in the input loudness
118
Compander State
This control is used to activate the on-board compressor/expander,
otherwise known as the compander.
124
Compression Ratio
This control will set the gamut range compression ratio. 48
Cr Gain
Varies the Source Cr. 45
Cr Offset
Varies the Source Cr. 45
Deinterlacer Mode
Sets whether the module will perform field or frame based de-
interlacing conversion.
52
Detail Gain
Selects the level of the detail gain. 49
Detail Noise Floor
Sets the minimum level of detail required before the enhancer is
enabled.
50
Down Mix Type
Sets the type of audio down mixing that will be performed. 95
Downmix Gain Adjust X
Sets the value of the gain from the selected source. 98
Downmix Gain Adjust Y
Sets the value of the gain from the selected source. 100
Downmix Invert Enable
X
Inverts the phase or passes the selected audio channels. 98
