Test Setup - Test Configurator, Timer, and System
144 88000 Series
Modify Structure Button
For Wireless Test Application
Note: For Dual Port topology each port is configurable individually. However for
eCPRI, both port interface/rate are coupled and in addition for 88260 they
are forced on the same transceiver system.
Interface/Rate allows the selection of the interface rate.
Connector is the module’s port available for the selected interface/rate
(see table above).
Test
Interface
Rate
Connector
a
a. Availability of connectors depend on the model.
8870/8880 88200NGE 88260
CPRI BERT CPRI - 1.2G
CPRI - 2.4G
CPRI - 3.1G
CPRI - 4.9G
CPRI - 6.1G
CPRI - 9.8G
CPRI - 10.1G
Port 1 - SFP+
Port 2 - SFP+
Port 1 - SFP+ Port A1/A2/B1/B2 - SFP28
OBSAI BERT OBSAI - 1.5G
OBSAI - 3.1G
OBSAI - 6.1G
eCPRI BERT 10G
25G - -
