Test Setup - Test Configurator, Timer, and System
Power Blazer 143
Modify Structure Button
For Fibre Channel Test Application
 Interface/Rate choices depend on the rates available on the module.
 Connector allows the selection of the module’s port available for the
selected interface/rate (see above table).
Interface/Rate
Connector
a
a. Availability of connectors depend on the model.
8870-8880 88200NGE 88260
1X
2X
4X
8X
10X
Port 1 - SFP+
Port 2 - SFP+
Port 1 - SFP+ Port A1/A2/B1/B2 -
SFP28
16X -
32X - -
