Test Setup - Test Configurator, Timer, and System
142 88000 Series
Modify Structure Button
 Connector: Allows the selection of the module’s port available for the
selected interface/rate.
Interface/Rate
Connector
a
a. Availability of connectors depend on the model.
8870/8880 88200NGE 88260
10GE LAN
1GE Optical
100M Optical
Port 1 - SFP+
Port 2 - SFP+
b
b. Not available with Wander.
Port 1 - SFP+ Port A1/A2/B1/B2 - SFP28
10/100/1000M Electrical Port 1 - RJ45 Port 1 - SFP+ (RJ45)
c
c. Ethernet 10/100/1000 Mbit/s electrical is supported when using an active copper SFP.
Port A1/A2/B1/B2 - SFP28
(RJ45)
d
10 MHz
2MHz
1PPS
BNC (Port labelled TX/RX2)
RJ48C
--
