Test Setup - Test Configurator, Timer, and System
Power Blazer 133
Modify Structure Button
 Connector allows the selection of the module’s port.
Interface/Rate Connector
a
a. Availability of connectors depend on the model.
8870/8880 88200NGE 88260 88400NGE 88460
400GE (8 Lanes)
[425 Gbit/s]
- - - Port 1 - CFP8 Port 1 - CFP8
Port 1 - QSFP56-DD
400GE (4 Lanes)
[425 Gbit/s]
- - - - Port 1 - OSFP
200GE (4 Lanes)
[212.5 Gbits/s]
--- - Port 1 - QSFP56-DD
100GE (4 Lanes)
[103.125 Gbit/s]
-Port 1 - CFP4
Port 2 - QSFP
b
b. This port accepts QSFP+ or QSFP28 transceivers.
Port A1/A2/B1/B2 -
QSFP28
Port A1/B1 - CFP4
--
40GE (4 Lanes)
[41.25 Gbit/s]
-Port 2 - QSFP
b
Port A1/A2/B1/B2 -
QSFP28
--
25GE - - Port A1/A2/B1/B2 -
SFP28
--
10GE WAN
10GE LAN
1GE Optical
100M Optical
Port 1 - SFP+
Port 2 - SFP+
Port 1 - SFP+ Port A1/A2/B1/B2 -
SFP28
--
10/100/1000M
Electrical
Port 1 - RJ45
Port 2 - SFP+
c, d
c. Only available as a second port when the test application requires two ports.
d. Ethernet 10/100/1000M electrical is supported when using an active copper SFP.
Port 1 - SFP+
d
Port A1/A2/B1/B2 -
SFP28 (RJ45)
--
