Test Setup - Test Configurator, Timer, and System
Power Blazer 243
Local Details (iSAM)
Interface/Rate or Port choices depend on the rates available on the
module.
For 10GE WAN, the test uses the WIS default values for J0, J1, and C2 as
defined in WIS Button on page 232.
PHY Type allows selecting the 100GE (4 Lanes) CFP4/QSFP transceiver
PHY type: LR4/ER4 (default), SR4, CWDM4, CLR4, AOC, or Other. The
PHY type when set to any except LR4/ER4, allows enabling RS-FEC
(see page 223); ensure both ends of the circuit have the FEC enabled.
Only available with 100GE (4 Lanes) framed Ethernet interface.
RS-FEC check box when selected (default), enables the use of the
RS-FEC; ensure both ends of the circuit have the FEC enabled. The
RS-FEC check box should be selected when using a 100GBASE-SR4,
100G-CWDM4, or 100G AOC transceiver but may be cleared for testing
purposes. Not available when the PHY Type is set to LR4/ER4.
100GE (4 Lanes) [103.125 Gbit/s]
40GE (4 Lanes) [41.25 Gbit/s]
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
a
a. For 88200NGE, only possible when using an active copper SFP.
