Test Setup - Test Configurator, Timer, and System
328 88000 Series
Signal
Min RX Power (dBm)
1
indicates, when supported, the minimum
received power level of the optical lane/laser in dBm.
Max RX Power (dBm)
1
indicates, when supported, the maximum
received power level of the optical lane/laser in dBm.
Laser ON/OFF button is used for parallel interfaces to activate the laser
control per optical lane or for all lanes.
Optical lane numbers are from 0 to 3 or 0 to 7 depending on the
selected interface/rate.
All Lanes check box, when selected, applies the change(s) to all
optical lanes at once.
Optical Lane indicates the optical lane numbers and All which
represents the setting for all optical lanes when the All Lanes
check box is selected.
Laser check box, when selected, indicates that the corresponding
optical laser lane is activated and emitting an optical laser signal.
Lasers OFF at Start-Up check box when selected automatically turns
OFF the laser for serial interfaces or all lasers for parallel interfaces
when starting the Power Blazer or when switching from one test
application to another. However the laser remains ON, on a remote
module receiving a request for a DTS connection or a loopback
command. This check box is cleared by default.
Power Range (dBm) indicates the transceiver operational RX power
range.
1. Displayed for each optical lane for parallel interfaces.
