Test Setup - Test Configurator, Timer, and System
332 88000 Series
Signal
Frequency (GHz) indicates the frequency of the input signal.
Offset (ppm) indicates the frequency offset between the standard rate
specification and the rate at the input signal.
Note: For both Frequency and Offset the following background colors are used:
Max. Negative Offset (ppm) indicates the maximum negative
frequency offset between the standard rate specification and the rate
from the received signal.
Max. Positive Offset (ppm) indicates the maximum positive
frequency offset between the standard rate specification and the rate
from the received signal.
Note: Refer to Interface on page 425 for more information on standard rate
specifications.
Signal Configuration
For OTN, refer to Signal - Signal Configuration (OTN) on page 341 for
more information.
For SONET/SDH, refer to Signal - Signal Configuration (SONET/SDH) on
page 345 for more information.
For DSn/PDH, refer to Signal - Signal Configuration (DSn/PDH) on
page 333 for more information.
Background color Description
Green The frequency is in range.
Red The frequency is out-of-range or LOC Lane. LOC is also
displayed.
Gray Pending state.
