Physical Interfaces and LEDs
26 88000 Series
Port Availability per Module
88260 and Transceiver Systems
The following table shows the list of transceiver system supported on each
port of the FTBx-88260 module.
The following table shows the list of port as well as a description and the
signals supported on each transceiver system.
Port
Labelled
Description Supported Transceiver System
A Transceiver system left port TA-SFP28, TA-QSFP28, TA-CFP4, TA-Sync
B Transceiver system right port TA-SFP28, TA-QSFP28, TA-CFP4, TA-Sync
Transceiver
System
Description
Port
Labelled
a
a. The ports are listed/referred as follows in the GUI: Port, FTBx-88260‘s port (A or B), transceiver system
port (1 or 2), and connector type; for example Port A1 - SFP28.
Supported Signal(s)
TA-SFP28 Dual SFP28 supporting
SFP/SFP+/SFP28
transceivers
1 Ethernet 100/1000 Mbit/s, 10 Gbit/s, 25 Gbit/s optical
Ethernet 10/100/1000 Mbit/s electrical (using active
copper SFP)
Fibre Channel 1X, 2X, 4X, 8X, 10X, 16X, 32X
eCPRI 10 Gbit/s, 25 Gbit/s
CPRI 1.2, 2.4, 3.1, 4.9, 6.1, 9.8, 10.1 Gbit/s
OBSAI 1.5, 3.1, 6.1 Gbit/s
OC-1/STM-0, OC-3/STM-1, OC-12/STM-4,
OC-48/STM-16, OC-192/STM-64
OTU1, OTU2, OTU1e, OTU2e, OTU1f, OTU2f
2
TA-QSFP28 Dual QSFP28 supporting
QSFP+/QSFP28
transceivers
1 QSFP+:
Ethernet 40 Gbit/s
OTU3e2, OTU3e1, OTU3
QSFP28:
Ethernet 100 Gbit/s
OTU4
2
TA-CFP4 CFP4 1 Ethernet 100 Gbit/s
OTU4
REF OUT (SMA) REF OUT Electrical port for eye diagram clock signal generation
TA-SYNC EXT CLK (SMB) EXT CLK IN: 2 MHz
OUT: 2 MHz
1PPS (SMB) 1 PPS IN: 1PPS
b
b. Used for Dual Test Set - One-Way Latency measurement mode.
ANTENNA (SMA) ANTENNA Future use
