Physical Interfaces and LEDs
28 88000 Series
Port Availability per Module
8870/8880
The following table shows the list of available ports as well as a description
and the signals supported for each module.
Connector Labelled Description and supported signal(s)
Module
8870 8880
Bantam BANTAM
TX/RX2
RX
TX and RX: DS1/1.5M, E1/2M
RX2: DS1/1.5M
-X
Clock IN/OUT: DS1/1.5M, E1/2M, 2 MHz
BNC BNC
TX/RX2
TX: E1/2M, E3/34M, DS3/45M, STS-1e/STM-0e/52M, E4/140M,
STS-3e/STM-1e/155M
RX2: DS3, 2 MHz, 10 MHz
-X
Clock OUT: DS1/1.5M, E1/2M, 2 MHz
BNC
RX
E1/2M, E3/34M, DS3/45M, STS-1e/STM-0e/52M, E4/140M,
STS-3e/STM-1e/155Mk, 1PPS
-X
Clock IN: DS1/1.5M, E1/2M, 2 MHz, 10 MHz, 1 PPS
BNC
EXT CLK
Clock IN: DS1/1.5M, E1/2M, 2 MHz, 1 PPS X -
RJ45 RJ45 P1 Ethernet 10/100/1000 Mbit/s electrical X X
RJ48C RJ48C DS1/1.5M, E1/2M X X
1PPS, 2 MHz, 10 MHz - X
Clock IN: DS1/1.5M, E1/2M, 2 MHz - X
Clock OUT: DS1/1.5M, E1/2M, 2 MHz - X
SFP/SFP+ SFP+ P1
or
SFP+ P2
Ethernet 100 Mbit/s, 1000 Mbit/s,10 Gbit/s LAN/WAN optical
OC-1/STM-0, OC-3/STM-1, OC-12/STM-4, OC-48/STM-16,
OC-192/STM-64
a
OTU1, OTU2, OTU1e, OTU2e, OTU1f, OTU2f
eCPRI 10 Gbit/s
CPRI 1.2, 2.4, 3.1, 4.9, 6.1, 9.8, 10.1 Gbit/s
OBSAI 1.5, 3.1, 6.1 Gbit/s
Fibre Channel 1X, 2X, 4X, 8X, 10X
a. Port SFP+ P2 is used with OC-192/STM-64 in Decoupled (TX≠RX) mode.
XX
SFP+ P2 Ethernet 10/100/1000 Mbit/s electrical (using active copper
SFP)
b
b. Available as a second port when the test application requires two ports.
XX
