Test Results
Power Blazer 405
Alarms/Errors Overview
Ethernet
Note: Available with EtherBERT, Wander, and OTN BERT with EoOTN client.
For Wander test application only Link Down alarm is supported.
Alarms
Note: For LOA, Inv. Mapping, LDegSERDet, LDegSERRcd, and R Deg SER
alarms see Ethernet - PCS on page 408.
 Link Down
RX: For 10/25/40/100/200/400G: There is a local or a remote fault
condition. For 100/1000 Mbit/s: No bits/clock sync (PMA/PMD Link
down), including LOS. For 10 Mbit/s: No data or no Normal Link Pulse
(NLP) are received.
 Local Fault Det
1
(Local Fault Detected)
RX: At least one of the following events is detected: Loss of bit
synchronization, Loss of Block synchronization, Link down, or High
BER.
 Local Fault Rcd
1
(Local Fault Received)
RX: The received data path contains the Local Fault signal.
 Remote Fault
1
RX: The received data path contains the Remote Fault status.
 Hi-BER (High-Bit Error Ratio) - (Available with 25/40/100GE interface,
and EoOTN 100 GbE client).
RX: The bit error ratio is > 10
-4
on a fixed time period; 2 ms for 25G,
1250 μs for 40G, and 500 μs for 100G.
1. Available with Ethernet 10/25/40/100/200/400 Gbit/s interface, Ethernet (flex/GFP-F) client, and EoOTN 10/40/100 GbE
client. Remote Fault is also available with EoOTN 1GbE client.
