Graphical User Interface Overview
34 88000 Series
Status Bar
Loopback Tool enabled on the port unused by the main test
application.
Ethernet
Clock synchronization signal clock. The clock icon is followed by the
clock mode: INT for Internal, EXT for External RCV for Recovered,
or BKP for Backplane. AUTO is displayed for dual port test when a
different clock is used on each port.
Green: Clock Synchronized.
Red: Loss of clock.
Transport
Ethernet
Fibre Channel
Wireless
Indicates a manual change in the OH bytes transmitted. Not displayed
when using the default OH values.
Transport
Remote PC connection established with the Power Blazer. N/A
The test is in loopback mode. Not displayed when not in loopback
mode.
NI-CSU Emulation
Alarm/error is currently injected. Not displayed when there is no
alarm/error injection.
Transport
EtherBERT
Carrier Ethernet OAM
Fibre Channel
Wireless
a. For all lanes for parallel interface.
b. For at least one lane for parallel interface.
Icon
and/or text
Description Test Application
