Test Results
474 88000 Series
Alarms/Errors Overview
Manual allows entering the amount of error to be generated:
1 (default) through 50 or 100 (depends on the selected error).
Rate allows the selection of the error injection rate. The rate must
be within the minimum and maximum values specified.
Max Rate generates the error to its theoretical maximum rate.
Period, for GFP layer, allows setting the alarm period associated with
the client management frames: 10 ms to 1200 ms (default is 100 ms).
User-Defined UPI available with GFP layer, allows entering the Client
Management Frame UPI value when GFP-User-Defined CMF alarm is
selected.
Lane, available with parallel interfaces, allows selecting the physical
lane that will be used for injection. Available for Interface, OTL, FEC
(FlexO), FOICx.y, and PCS layers only.
The following settings are available with FlexE:
FlexE allows selecting the PHY, Group, or Client level used for
injection.
Client ID allows selecting the client ID used for injection.
PHY allows selecting the PHY number that will be used for injection.
The following settings are available with FlexO:
Category allows selecting either PHY, FlexO, OTN, or Client Payload
level used for injection.
Port available for FlexO PHY level allows selecting the physical port
number.
UPI Description for PTI = 100
0000 0000 and 1111 1111 Reserved
0000 0001 Client Signal Fail (Loss of Client Signal)
0000 0010 Client Signal Fail (Loss of Client Character Synchronization)
0000 0011 through 1111 1110 Reserved for future use
