Test Results
Power Blazer 475
Alarms/Errors Overview
 Client ID indicates the client ID used for injection.
 Instance available at FlexO level allows enabling the FlexO instance
number(s) used for injection.
 OTUC available at OTN level allows enabling the OTUC number(s)
used for injection.
The following settings are available with Carrier Ethernet OAM:
 Address Type defines the destination address type of the frame:
Unicast or Multicast (default).
 Priority
1
allows selecting the VLAN user priority: 0 (default) to 7.
Refer to VLAN ID and Priority on page 842 for more information.
 Drop Eligible
1
is set to No (no frames will be dropped when
congestion occurs) and is not configurable.
 MEG Level (Y.1731 and MEF) is the Maintenance Entity Group
Level configurable from 0 to 7 (default).
 MD Level (802.1ag) is the Maintenance Domain Level and is
configurable from 0 to 7 (default).
 Period determines the transmission period of frames: 1 s (default)
and 1 min. Not available with C-DCI.
 Amount, only available with C-DCI alarm, is set to 1.
Note: The RDI alarm is available when the CC Function is enabled and is using
the parameters from the CC Function (refer to page 310).
1. Available when VLAN is enabled (see VLAN on page 268).
