RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
89
Resolving the Printer pausing between Panels problem
Symptom: The Printhead Fan is not operating properly.
Step Procedure
1 Confirm that the fan operates correctly.
a. Upon power up, the fan should run momentarily and shut off.
b. Verify that the fan is plugged into the Main Print Board properly on J67.
2 Check the Printhead fans for pinched wires.
a. Inspect the wires that are routed under the top cover and through to the
back of the Board to ensure that they are not pinched.
3. Verify if the thermal regulator on the Printhead has failed.
a. Remove the Printhead and reseat cable connections.
b. If problem persists, replace with a new Printhead, as described in the
Replacing the Printhead (D840854)
procedure in Section 5, page 281.
4 Ensure that the Printer has received data (at the speed that it requires). See
Communication Errors
in Section 2, page 60.
