RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
460
Adjusting the Image Darkness
Step Procedure
1
Choose MENU, Print Test Image and Gray/Align YMC to print a test card.
2 Examine the test card.
3
Select MENU, Setup Printer and Image Darkness.
4
Record the Image Darkness value on the test card last printed.
5 Enter a negative value to lighten the printed image.
OR
Input a positive value to darken the printed image. (Note: Be sure to make
adjustments in small increments of ± 4, to avoid over-adjusting this setting.)
Caution: The ribbon may jam or break if the setting is too high.
6
Press SELECT to save the value.
7 Print a test card as described in Step 1.
8 Repeat Steps 1 to 7 until the image darkness is correct.
