RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
43
Reviewing the Rejection Card Hopper and Card Output Hopper
Component Description Reference
Rejection
Card Hopper
The Rejection Card Hopper helps to
separate potentially bad cards from a stack
of good cards, which eject into the Card
Output Hopper.
The Printer will automatically eject cards
into this hopper to indicate:
• There is a printing error, laminating
error or encoding error.
• There is a card is left in the Printer after
a print job is canceled or the Printer
restarted.
See the Using the
Lamination tab (only with
the Card Lamination
Module) in Section 5, page
238.
Card Output
Hopper
Stores up to 100 printed cards (30 mil
cards).
a. When the hopper has reached its
maximum capacity of cards, note that
the operation pauses and an Output
Hopper Full message appears on the
Printer's LCD Display.
b. Remove the stack of cards from the
hopper.
c. Press the Lamination Module's Resume
button to continue. (Note: If printing
onto oversized cards, the Card Output
Hopper Door should be placed in the
open position in order for these larger
cards to eject properly.)
See the Using the
Lamination tab (only with
the Card Lamination
Module) in Section 5, page
238.
