RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
444
Section 9: LCD On-Line Menu Navigation
The purpose of this section to provide the User with specific procedures for LCD On-Line
Menu Navigation, Test Image Printing and Printer Setup for the HDP 820 Card Printer.
Entering the LCD Menu and selecting an Option
The MENU option is above the center softkey button, as shown below. This allows you to
access several test, setup and reporting functions. The Selecting from the Menu Option Tree
Structure in Section 8, page 446, shows the available menu options. A description of each
option and its function is included on the pages following the on-line menu.
Step Procedure
1
Press the MENU button to bring up the SELECT FUNCTION screen appears, as
shown here.
Ready
HDP820
SELECT
HELP
[Print Test Image]
Setup Printer
Continued on the next page
