HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
21
Printer Components: Access Card Slot to Parallel Interface Port (continued
Component Description
Scroll Buttons Used to scroll through menus and sub-menus and to adjust certain
menu options.
Transfer Station Transfers printed images and the HDP film to blank cards.
Unlock Release Lever
to open Print and
Transfer Stations
Print Station
Transfer Station
