RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
45
Reviewing the Module and LCD Display interaction
Term Description Reference
Module
and LCD
Display
interaction
For ease of operation, the Card
Lamination Module works in tandem with
the Printer's LCD Display to communicate
status message such as when an error
occurs or when it is time to replace the
overlaminate material.
If a Lamination error does occur, the
Lamination Module's LED will flash and
an attention level message will appear on
the Printer's LCD Display. (Note: Since it
is an ATTENTION level message, it will
not interrupt printing.)
a. Correct the error.
b. Press OK to clear the LCD's
ATTENTION message.
c. Press the Lamination Module's
Resume button to resume operation
or its Cancel button to cancel the
current Lamination job and accept the
next. (Note: If canceled, the canceled
card will eject into the Rejection Card
Hopper.)
See the Using the Lamination
tab (only with the Card
Lamination Module) in Section
5, page 238.
Continued on the next page
