RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
213
Defining the Area to activate the Card Grid
Step Procedure
1
Select on the appropriate Defined Area (see below) to activate the card grid in the
upper half of the window.
• It is through this card grid that up to five areas can be defined, as shown
below.
• When the card grid is first activated, then a small black square will appear at
its default size of .2" x .2" (5mm x 5mm) and at its default location in the lower
left-hand corner (0,0). (Note: This square represents the first defined area.)
