RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
42
Reviewing the Resume (pause) button
Component Description Reference
Resume
(pause)
button
Press the Resume button to resume
operation after an error condition is
cleared.
• If an error occurs, the Lamination
Module's LED will flash and the
Printer's LCD will report the specific
error.
• If this happens, correct the error and
press the Lamination Module's
Resume button to continue printing.
Press this button to pause the
Lamination Module during normal
operation. (Note: The Lamination
Module will always finish its current task
before pausing.)
• If this button is pressed while a card
is being laminated, the Lamination
Module will pause only after the
current card has finished laminating
and the Lamination Module has
reached a safe stopping point.)
• If the Printer is paused, the LED
Light will flash slowly and will return
to solid when operation is resumed.
(Note: With the Lamination Station
open, the Pause button can also be
used to manually rotate the feed
rollers backward. This is helpful
when cleaning the rollers or when
clearing jammed media.)
See the Using the Lamination
tab (only with the Card
Lamination Module) in Section
5, page 238.
