RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
459
Setting the Flattener Temperature
The Flattener Temperature controls the heat of the Flattener. (Note: The Flattener will
straighten a card after the image has been transferred to it. This may be adjusted from the
LCD Menu or from the Image Transfer tab of the Driver.)
Setting the Printhead Resistance
Step Procedure
1 Locate the Printhead Setting Number on the bottom of the Printhead.
The number reads R=XXXX.
2
Select MENU, Setup Printer and Printhead Resistance.
3
a. Input the Printhead Setting Number. (Note: The Printhead Resistance
setting in the LCD Setup changes in increments of 50.)
b. To select the proper resistance value, choose the setting that is closest to the
value on the Printhead.)
4
Press the Select button to save the value.
