RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
441
Reviewing the Sensor Location and Voltages
Sensor Location Pin Board Low Range VDC High Range VDC
Upper Film
Sensor
J66 8 Print Blocked 0 Unblocked +5
Upper Film
Encoder
J66 4 Print Unblocked .17 Blocked 3.0 - 3.3
Lower Film
Sensor
J65 8 Lam Covered .9 Uncovered 3.5 - 5.0
Lower Film
Encoder
J65 4 Lam Unblocked .17 Blocked 3.0 - 3.3
Card Position
Sensor
J62 4 Lam Unblocked .17 Blocked 3.0 - 3.3
Ribbon
Encoder
J64 4 Print Unblocked .17 Blocked 3.0 - 3.3
Flipper Table
Card Sensor
J58 4 Lam Unblocked .17 Blocked 3.0 - 3.3
Flipper Table
Sensor
J64 8 Lam Covered .9 Uncovered 3.0 - 3.3
Card Hopper
Sensor
J64 12 Lam Covered .9 Uncovered 3.0 - 3.3
Card Input
Sensor
J64 4 Lam Unblocked .9 Blocked 3.0 - 3.3
Printhead lift
Sensor
J64 8 Print Unblocked .9 Blocked 3.0 - 3.3
Transfer Lift
Sensor
J65-12 2 Lam Unblocked .9 Blocked 3.0 - 3.3
Lower Dancer
Sensor
J62 8 Lam Covered .9 Uncovered 3.0 - 3.3
Upper Dancer
Sensor
J62 12 Lam Covered .9 Uncovered 3.0 - 3.3
Continued on the next page
