FARGO electronics HDP820 - Preparing to Adjust the Print Offset, Transfer TOF and Transfer EOF

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
449
Preparing to Adjust the Print Offset, Transfer TOF and Transfer EOF
Step Procedure
1 Before starting the alignment procedures, you must first establish a baseline
from which to start the adjustments.
2
Select MENU, Setup Printer.
3
Select the Print Offset button.
4
Set to –32 and press the Select button.
5
Select Transfer TOF.
6
Set to +40 and press the Select button.
7
Select the Transfer EOF button.
8
Set to –24 and press the Select button.
