RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
132
Printing a Test Image
Step Procedure
1
Choose Print Test Image to select a preset test image. (Note: These images
help to determine if the Printer is functioning properly.)
2
Scroll to the desired test image from the Select Test Image options and press the
Select button.
Reviewing the Gray/Align YMC/K Self-Test
Step Procedure
1 Use this card to determine Image Placement and confirm that the Printer is
working properly. See Printer Setup
in Section 8, page 447. (Note: The image
consists of sixteen (16) gray scale boxes and alignment arrows. The gray boxes
are composed from a composite of YMC color panels.))
