Reviewing the Color/Resin YMCK Self-Test
Step Procedure
1 Use this card to determine Image Placement and confirm that (a) the image colors
are properly reproduced and (b) the Resin Panel is printing properly. (Note: The
Image consists of twelve spot colors, YMC and RGB, as well as gray density bars
and thin resin lines.)
Reviewing the Color Bars YMC Self-Test
Step Procedure
1 Use this card to confirm that image colors are properly reproduced. Image consists
of sixteen graduated steps of RGB and YMCK. (Note: This print will provide
maximum image size, giving complete card coverage on a CR-80 sized card.)
