RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
71
Resolving the stalled Cards on or at the Feed Rollers
Step Procedure
1 Clear the stalled card.
a. Open the Print and Transfer Station.
b. Use the arrows on the LCD panel to move the card forward or backward to
free the card.
2 Inspect the Card Feed Roller Motors for proper operation.
a. Leave the power ON and open the Print and Transfer Stations.
b. Press the FORWARD button to advance the card or the BACK button to
reverse the card. (Note: Use these buttons to move the card through the
Printer.)
c. Verify that there is nothing obstructing the card as it travels through the
Printer.
Resolving the jammed Cards on the Flipper Table
Step Procedure
1 Clear the jammed card.
a. Open the Print and Transfer Station.
b. Use the arrows on the LCD panel to move the card forward or backward to
free the card.
2 Inspect the Card Feed Roller Motors for proper operation.
a. Leave the power ON and open the Print and Transfer Stations.
b. Press the FORWARD button to advance the card or the BACK button to
reverse the card. (Note: Use these buttons to move the card through the
Printer.)
3 Adjust the Flipper Offset.
a. Select the Menu on the LCD Display.
b. Select the Setup Printer. Scroll down to the Flipper Offset.
c. Change the setting on small increments. (Note: A positive adjustment will
lower the side of the Flipper Table closest to the Exit Hopper.)
d. Press Select to save the new value.
