RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
14
Technical Specifications (continued)
Term Description
Maximum Accepted
Card Width Range
(HDP825/825-LC only) 2.125 in. to 2.63 in. (54mm to 67mm).
Maximum Accepted
Card Length Range
3.375 in. to 3.88 in. (85.6mm to 98.5mm).
Memory 8 MB RAM; expandable to 32 MB RAM.
Operating
Temperature
65ºF to 80ºF (18ºC to 27ºC).
Options The options are the 32MB RAM Upgrade Kit, Printer Cleaning Kit,
External Print Server (Windows only; required for stand-alone
networking of printer/encoders), Card Lamination Module and USB-
to-Parallel Interface Cable (Windows 98/Me/2000/XP only).
Output Hopper
Card Capacity
100 cards (.030"/.762mm); 250 cards with optional Card Output
Stacker
Overlaminate
Options (HDP800
Series-LC only)
All overlaminates are available in either clear, holographic globe
design or custom holographic design. They can also be optimized
for use with smart cards and Magnetic Stripes. PolyGuard available
in CR-80, CR-90 and CR-100 patch sizes. Here are the options:
• Thermal Transfer Overlaminate, .25 mil thick, 500 prints
• PolyGuard Overlaminate, .6 mil thick, 250 prints
• PolyGuard Overlaminate, 1.0 mil thick, 125 prints
Print Area Over-the-edge on all accepted standard card sizes (YMCKH ribbon
required for over-the-edge printing on CR-100 cards).
Print Method HDP Dye-Sublimation/Resin Thermal Transfer
Printing Method HDP™ Dye-Sublimation/Resin Thermal Transfer.
Printing Resolution Up to 16.7 million colors and 256 shades per Pixel.
Continued on the next page
