RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
453
Setting the Transfer TOF (continued)
Step Procedure
3
Record the Transfer TOF value on the test card last printed.
4 Select MENU, Setup Printer and Transfer TOF.
5 Measure the distance from the leading edge of the card to the leading edge of
the transferred image.
6
Calculate the Transfer TOF value for inches or mm.
• Inches: 40 – (Measurement x 300)
• Millimeters: 40 – (Measurement x 11.8)
Example: Inches: 40 – (.050 x 300) = 45:
7
Adjust the Transfer TOF value.
8
Press SELECT to save the value.
9 Print a test card as described in step 1.
10 Repeat Steps 1 to 9 until the test image is correctly positioned.
