RESTRICTED USE ONLY Fargo Electronics, Inc.
HDPî 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
463
Setting the Magnetic TOF
Step Procedure
7
Press SELECT to save the value.
8 Test the position of the Start Sentinel by magnetically encoding a card and
checking as described in Step 1 in this same procedure.
9 Repeat Steps 1 to 6 until the Magnetic TOF is correct.
Magnetic Track Data
Trailing Edge
of Card
Leading Edge
of Card
