Updating the Main Firmware (continued)
Step Procedure
8
Wait: The Firmware update will now take a few minutes.
Check the Printer's LCD for the status. (Note: When the update is complete, the
LCD will indicate if the update was successful.)
9
If the Upgrade Successful is displayed, click on Exit on the Sending Update to
Printer dialog screen.
10
Press the Printer's Exit button.
11 When prompted, turn the Printer power OFF for a few seconds and then back
ON to complete the update process. (Note: As the Printer restarts, you will see
the new Firmware version appear on the LCD.)
12
a. If the upgrade was not successful, the LCD will either display Upgrade
Failed or Upgrade Firmware Now on boot up.
b. If you receive this message, try updating the Firmware again.
