HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
24
Printer Components: Access Card Slot to Parallel Interface Port (continued)
Refer to the previous table.
LCD Display
LED Light
Softkey Buttons
Card Cleaning
Assembly
Card Input Hopper
Card Thickness
Adjustment Knob
Front Access Door
Card Output
Hopper
Print Station
Release Lever
Transfer Station
Film Tension
Knobs
Printhead
Access
Card Slot
Scroll Buttons
