HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
30
Step
Procedure
5
Remove 4 screws (F000192) that attach the Main Chassis to the Card Path.
6
Slide the Card Path away from the Main Chassis.
7
Disconnect all wire connection (or as many as are needed for access).
Each cable end is labeled with the part number for ease of matching the connections.
