Fargo HDP8500 - Page 34

HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
34
Step
Procedure
5
Disconnect the Film Sensor and Lam Lift Sensor cables from the Transfer Arm connection.
6
Caution: Do not damage the Mainboard when removing or installing the Main
Chassis.
Carefully rotate the chassis up and off of the frame.
