Fargo HDP8500 - Page 74

HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
74
Step
Procedure
4
IMPORTANT NOTE: Tilt the roller when replacing back into the frame- DO NOT scratch the
roller.
Final position before replacing the assembly.
5
Reverse the instructions to re-assemble.
Refer to Appendix A for Cable Connection diagram.
