HDP8500 Service Manual, PLT-01583, 1.1
© 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
83
Step
Procedure
19
Lift out the Printhead Motor Mount assembly.
20
Carefully lift out the complete Printhead Assembly (D910515).
