Section 5: Using the Model 9500B — Procedure Mode — Contents 5.1-1
Final Width = 215mm
Descriptions assume 9500B/1100
5.1 About Section 5
Section 5 Using the Model 9500B — Procedure Mode
Section 5 is a guide to using procedure card in
the 9500B, to calibrate manually-operated
oscilloscopes (UUTs). For a guide to using
front panel controls in Manual Mode, please
turn to Section 4.
Because the actual procedures are contained
within the cards, this section is limited to
general points, and access to the programs on
the cards. Section 5 is divided into the following
sub-sections:
page
5.1 About Section 5 (this sub-section).
5.2 Procedure mode — Safety and General Notes.
5.2.1 Introduction .................................................... 5.2-1
5.2.2 Safety Features ............................................... 5.2-1
5.2.3 General Notes ................................................. 5.2-1
5.2.4 Printing Setup ................................................ 5.2-2
5.2.5 Saving Results on Memory Cards .................. 5.2-3
5.3 Procedure mode — Access Guide.
5.3.1 Introduction .................................................... 5.3-1
5.3.2 Mode Selection .............................................. 5.3-1
5.3.3 Selection of Procedure Mode — Entry Menus
Common to All Procedures ............................ 5.3-1
