7-8 Section 7: Model 9500B — Specifications
Final Width = 215mm
7.9 Other Output function Specifications
Zero Skew
Unadjusted Skew: <±50ps ch to ch
Adjusted Skew: <±5ps ch to ch
Skew Temp Coef <0.2ps/˚C
Rise and Fall Time 450ps (typical)
Relative Jitter <7ps pk-pk
7.9.5 Zero Skew
Overload Pulse
Amplitude: 5V to 20V into 50Ω
Polarity: Positive / Negative
Duration: 0.2s to 100s
(subject to pulse energy limits)
Energy: 1.6J to 50J
Power in 50: 0.5W to 8W
Trigger: Manual Max Rep Rate 0.3Hz
(Internally Limited)
7.9.4 Overload Pulse
7.9.3 LF Linear Ramp
LF Linear Ramp
Waveforms: 1V pk-pk triangle symmetrical
about ground
Linearity: <±0.1% deviation over 10 - 90%
Ramp Time: 1ms, 10ms, 100ms or 1s
The 9560 Head is restricted to 50Ω loads only.
Composite Video Output
Amplitude: 1.0Vpk-pk
Pattern: (Full Raster) White, Grey or Black
Sync Polarity: Positive or Negative
Standards: 625-line 50Hz
525-line 60Hz
Trigger Output: Composite Sync or Odd Field start
9560 50Ω only
7.9.2 Video Output
Current DC Squarewave
Amplitude: ±100µA to ±100mA ±100µA to ±100mA pk-pk
Accuracy : ±(0.25% + 0.5µA) ±(0.25% + 0.5µA)@ 1kHz
Ranging: Amps/div ranging 1, 2, 5 or 1, 2, 2.5, 4, 5
or continuously variable
Frequency: 10Hz to 100kHz
Duty Cycle & Symmetry: 50%, symmetrical about ground
Rise Time and Aberrations <150ns and <±2% pk
Requires 9530 or 9510 Head and BNC Current adaptor
7.9.1 Current Function (Not available via 9550 Active Head)
