8.4.3 Printing Setup
Apart from the heading: Base, Heads, All and
Fast test results have the same printed layout.
The results of tests on all test pathways are
collected together in a table. A typical sample
of a table is given below:
The results of Base, Heads, All and Fast selftest
operations can be printed directly via the rear
panel parallel port J103. A suitable printer
must be connected and switched on-line; then
the 9500B internal program will generate the
required results.
8.4.3.1 Printer Type
The printer to be used should be capable of
printing 120 characters per line, and must be
able to print the Code Page 437 character set.
Most printers compatible with Epson FX,
Canon Bubble-Jet or Hewlett-Packard Desk-
Jet are suitable.
8.4.3.2 Data Formatting
The required printout style, format and data is
pre-determined depending on whether Base,
Heads, All and Fast test results are being
printed, and on the type of printer to be used. It
is necessary to enable a particular printer type
via Configuration mode, only if the format for
that printer is required.
Note: If the printer is disabled (Config mode
—Volume 1, Section 3, paras 3.3.2.6),
the printer will not be set up when
starting to print for the first time.
8.4.4 Results Printout
TEST PT MEAS VALUE NOMINAL MIN LIMIT MAX LIMIT ERR % FAILURES
DØ8.ØØ1 +5.289216 +5.ØØØØØØ +4.5ØØØØØ +5.ØØØØØØ +6Ø
DØ8.ØØ2 -5.486493 -5.2ØØØØØ -5.6ØØØØØ -4.ØØØØØØ -72
DØ8.ØØ3 +14.646128 +15.ØØØØØØ +14.25ØØØØ +15.75ØØØØ -47
Serial No: XXXXX S/W Issue: X.XX Date: XX/YY/ZZZZ Time: 12:41 Type: ALL
ERR % gives the achieved percentage of full tolerance for that test.
FAILURES In this column a failure is shown by the figure '1' against the relevant test.
