Section 2: Installing the Model 9500B 2-3
MADE IN THE EC
CAL
ENABLE
DISABLE
FACTORY SET
IEEE-488
SH1 AH1 T6 L4 SR1
RL1 PP0 DC1 DT0 C0 E2
PARALLEL PORTSERIAL PORT
6
78
CALIBRATION SEAL
SAFETY WARNING
1)
DISCONNECT POWER AND SIGNAL LEADS
BEFORE REMOVING COVERS.
2) FOR CONTINUED PROTECTION AGAINST ELECTRIC SHOCK
THE POWER CORD PROTECTIVE CONDUCTOR MUST BE
CONNECTED TO EARTH (GROUND).
3)
FOR CONTINUED PROTECTION AGAINST FIRE
FIT 250V FUSE OF CORRECT RATING
NOTE.
NO USER SERVICEABLE PARTS CONTAINED. DO NOT
REMOVE COVERS, HAZARDOUS VOLTAGES PRESENT.
REFER SERVICE TO QUALIFIED PERSONNEL.
LINE VOLTAGE
SELECTION
FUSE 5 x 20mm
IEC 127
100V/ 120V
220V/ 240V
T10.0 AH
T5.0 AH
POWER INPUT 400VA max FREQUENCY 47- 63 Hz
REF FREQUENCY
OUTPUT
1V pk-pk nom
into 50Ω
REF FREQUENCY
INPUT
≤ 5Vpk
50Ω
AUXILIARY
INPUT
≤ 40Vpk
9500B Rear Panel
2.7 Preparation for Operation
IMPORTANT:
Refer to the Safety Issues section at the front of this manual, together with additional information in the Model 9500B General Specifications,
including Environmental Conditions: Section 7, sub-section 7.1.
Before preparing the Model 9500B calibrator for operation, note the danger warning:
DANGER
THIS INSTRUMENT IS CAPABLE OF DELIVERING AN ELECTRIC SHOCK. UNDER NO CIRCUMSTANCES TOUCH ANY
INSTRUMENT TERMINAL UNLESS YOU ARE FIRST SATISFIED THAT NO DANGEROUS VOLTAGE IS PRESENT.
Other than the main output active head connectors, the connections to the 9500B are via the rear panel:
2.7.1 Mounting: overleaf
→
