2-4 Section 2: Installing the Model 9500B
Option 90 permits the instrument to be mounted
in a standard 19 inch rack. The method of
fitting this option is described below, the
locations being shown in Fig. 2.1.
A. Provision of Option 90
1. Option 90 is provided with all necessary
attachments and fixings.
2. The 9500B is fitted with side extrusions
with holes to accommodate rack mounting
fixing screws.
B. Fitting the Mountings to the 9500B
1. Fit left and right front rack mounting ears
(these are interchangeable) to the 9500B:
a. Assemble the handles to the front ears
as shown in the diagram, and secure
using the four M4 x 12 POZICSK
screws provided.
b. Secure the front ears through the side
extrusions to the chassis, with the
brackets at the front as shown. Use
two M5 x 20 POZIPAN screws, plain
and shakeproof washers provided,
through the lower holes of each ear.
2. Fit left and right rear rack sliders (these are
interchangeable) to the 9500B:
Secure both sliders through the side
extrusions to the chassis, at the rear as
shown. Use the four M5 x 20 POZICSK
screws provided..
C. Removing the 9500B Feet and Tilt Stand
(if required)
Remove the feet and tilt stand:
a. Prize off the rubber pads from the four
feet.
b. Undo the two securing screws from
each foot. This releases the feet,
washers and tilt stand so that they can
be detached and stored safely for
possible future use.
D. Fitting the Rear Ears to the Rack
Fit the left and right rear ears (not
interchangeable) to the rack:
a. Fit the eight M6 cage nuts into the
correct cutouts at front and rear of the
rack (see Fig. 2.1). Squeeze the cage
on each nut and insert from the inside
of the rack.
b. Offer up each appropriate ear to the
outside of the back of the rack, with the
tongue facing forward as shown in the
diagram. Secure the ears using four of
the eight M6 x 16 chromium-plated
POZIPAN screws and four M6
washers.
E. Fitting the 9500B into the Rack
With assistance, slide the instrument into
the rack, locating the rear ears in the sliders
on the side extrusions. Push the instrument
home, and secure the front ears to the rack
using the other four M6 x 16 chromium-
plated POZIPAN screws and four M6
washers.
2.7.1 Mounting
2.7.1.1 Bench Mounting
The instrument is fitted with four plastic feet
and a tilt stand. It can stand flat on a bench,
positioned so that the cooling-air inlet on the
right side and exhaust apertures on the left side
are not obstructed.
2.7.1.2 Option 90 — Rack Mounting (Fig. 2.1)
2.7 Preparation for Operation (Contd.)
