Section 7: Model 9500B — Specifications 7-7
Final Width = 215mm
7.8 Pulse Width Function Specification
Pulse Width: 1n to 100ns
Accuracy: < ±5% ±200ps
Adjustment Resolution: 1ns to 4ns, <50ps
4ns to 20ns <250ps
20ns to 100ns <1ns
Rise and Fall Time: 450ps (typical)
Aberrations: < ±5% pk (typical)
Width Stability: < 10ps pk-pk 10mins/1˚C
Pulse Jitter: (wrt Trigger) < 5ps pk-pk
Frequency: 1kHz to 1MHz
Amplitude: 1V pk-pk into 50Ω
7.8.1 Pulse Width Function (Not available via 9550 Active Head)
