7.3 Voltage Function Specification DC
7.3.1 Voltage Function (Not available via 9550 Active Head)
Output Current: 140mA max. for Vout <22.24V; 20mA max. for Vout >22.24V
Waveform Settling Time: 200ms to 0.01% for DC or
≥270Hz square wave, increasing to 3s for 0.01% at 10Hz (extends to 600ms max. if instruction crosses
a safety threshold or if an Output On is involved)
Note 1 Accuracy specification excludes variability of resistance losses in mating BNC or PC3.5 connectors.
DC Square Wave
Into 1M
Ω Into 50Ω Into 1MΩ 9530 into 50Ω (Note1) 9560 into 50Ω(Note1)
Amplitude ±1mV to ±200V ±1mV to ±5V 40µV to 200V pk-pk 40µV to 5V pk-pk 40µV to 5V pk-pk
Accuracy (<10kHz): ±(0.025% + 25µV) ≥1mV ±(0.1% + 10µV) ≥1mV ±(0.1% + 10µV) ≥1mV ±(0.2% + 10µV)
<1mV ±(1% + 10µV) <1mV ±(1% + 10µV) <1mV ±(1% + 10µV)
Ranging: Volt/div factors of 1, 2, 5 or 1, 2, 2.5, 4, 5; or continuously variable
Deviation: ±11.2% (Including over and under-range)
Rise/Fall Time: <100Vpk-pk <150ns; ≥100Vpk-pk <200ns
Aberrations: <2% peak for first 500ns; <0.1% after 500ns; <0.01% after 100us
Frequency: 10Hz to 100kHz
Frequency Accuracy: ±0.25ppm
Frequency Ranging: 1, 2, 5 or 1, 2, 2.5, 4, 5 or continuous
DC into 1MΩ available at all heads simultaneously for accelerated multi-point DC linearity testing.
