Fluke 9500B - Levelled Sine Function Specifications

Section 7: Model 9500B — Specifications 7-5
Final Width = 215mm
7.6 Levelled Sine Function Specification
9500B/600 9500B/1100 9500B/3200 with 9530 Head 9500B/3200 with 9560 Head
Frequency Range: 0.1 Hz to 600 MHz 0.1 Hz to 1.1 GHz 0.1 Hz to 3.2 GHz 0.1 Hz to 6.4 GHz
Frequency Uncertainty: ≥12kHz ±0.25ppm, <12kHz ±3ppm
Amplitude (pk-pk): 0.1Hz - 550MHz: 0.1Hz to 550MHz: 0.1Hz to 550MHz: 0.1Hz to 550MHz:
(into 50Ω) 5mV to 5V 5mV to 5V 5mV to 5V 5mV to 5V
550MHz-600MHz: 550MHz to 1.1GHz: 550MHz to 2.5GHz: 550MHz to 2.5GHz:
5mV to 3V 5mV to 3V 5mV to 3V 5mV to 3V
2.5GHz to 3.2GHz: 2.5GHz to 3.2GHz:
5mV to 2V 5mV to 2V
3.2GHz to 6.4GHz:
25mV to 2V
Amplitude Accuracy: ±1.5% at single Ref Frequency (50 kHz - 10MHz)
Flatness wrt Ref Freq: 0.1Hz to 300MHz 0.1Hz to 300MHz: 0.1Hz to 300MHz: 0.1Hz to 300MHz:
Into VSWR of 1.6:1 (1.2:1) ±4% (±2%) ±4% (±2%) ±4% (±2%) ±2% (±2%)
300MHz to 550MHz: 300MHz to 550MHz: 300MHz to 550MHz: 300MHz to 550MHz:
±4% (±2.5%) ±4% (±2.5%) ±4% (±2.5%) ±2.5% (±2.5%)
550MHz to 600MHz: 550MHz to 1.1GHz: 550MHz to 1.1GHz: 550MHz to 3.0GHz:
±5% (±3.5%) ±5% (±3.5%) ±5% (±3.5%) ±3.5% (±3%)
1.1GHz to 3.2GHz: 3.0GHz to 6.0GHz:
±5% (±4%) ±5% (±4%)
Source VSWR:(typical) <1.35:1 <1.35:1 <1.35:1 <550MHz:
<1.1:1
550MHz to 3.0GHz:
<1.2:1
3.0GHz to 6.0GHz:
<1.35:1
Amplitude Ranging: Volts/div ranging 1, 2, 5 or 1, 2, 2.5, 4, 5 or continuously variable
Deviation: ±11.2% (Including over and under-range)
Harmonic Purity: 2nd Harmonic <-35dBc; 3rd Harmonic <-40dBc in 12GHz
Non & Sub Harm' Purity
1
: <-40dBc <6.0GHz: <-35dBc
Frequencies above 500MHz are not recommended for 1M input applications.
The 9560 Head is restricted to 50Ω loads only.
7.6.1 Levelled Sine Function ((Not available via 9550 Active Head))
1
For offsets >10kHz.
