Section 2: Installing the Model 9500B 2-1
2.2 Lifting and Carrying the 9500B
Caution! The 9500B weighs in excess of 12kg, so take special
care when lifting and carrying the instrument.
2.2.1 Lifting and Carrying from Bench Height
1. Disconnect and remove any cables from the rear panel.
2. The 9500B center of gravity is concentrated at the rear. Tilt the unit
so that it is standing vertically on its rear panel, with the feet towards
you, at the edge of the bench.
3. Grasp the instrument at the bottom (rear panel) corner furthest away
from you, and tilt it slightly to rest against you. Take the weight and
carry it vertically at the same height, making sure that it remains
resting against you.
4. Place the 9500B down at the same level by setting it vertically on
to the surface, then swivel it so that it can be tilted back on to its feet.
2.2.2 Lifting and Putting Down at Low Level
1. Always bend your knees, not your back, when going down. Keep
your back as straight and as vertical as possible.
2. Use the same technique (2.2.1 - 3 above) to hold the instrument's
center of gravity close to you.
Section 2 Installing the Model 9500B
2.1 About Section 2
Section 2 contains information and instructions for unpacking and
installing the Model 9500B Universal Calibration System. It is divided
into the following sub-sections:
page
2.2 Lifting and Carrying the Model 9500B
2.2.1 Lifting and Carrying from Bench Height ................................. 2-1
2.2.2 Lifting and Putting Down at Low Level ................................... 2-1
2.3 Unpacking and Inspection ...................................................................2-2
2.4 Storage ............................................................................... 2-2
2.5 Preparation for Shipment .................................................................... 2-2
2.6 Calibration Enable Switch ................................................................... 2-2
2.7 Preparation for Operation .................................................................... 2-3
2.7.1 Mounting ................................................................................2-4
2.7.1.1 Bench Mounting .....................................................2-4
2.7.1.2 Rack Mounting .......................................................2-4
2.7.2 Power Input ............................................................................2-6
2.7.3 Power Cable........................................................................... 2-6
2.7.4 Power Fuse ............................................................................2-6
2.7.5 Line Voltage ........................................................................... 2-7
2.8 Connectors and Pin Designations
2.8.1 IEEE-488 Input/Output Socket ............................................... 2-7
2.8.2 Parallel Port............................................................................ 2-8
2.8.3 Serial Port ..............................................................................2-8
2.8.4 Auxiliary Input......................................................................... 2-9
2.8.5 Ref Frequency Input............................................................... 2-9
2.8.6 Ref Frequency Output ............................................................ 2-9
2.9 Care of Microwave Connectors ...........................................................2-9
