Section 7: Model 9500B — Specifications 7-1
Final Width = 215mm
SECTION 7 9500B SPECIFICATIONS
7.1 General
7.2 Accuracy Specifications
All Specifications apply at TCal ±5°C, where Factory TCal = 23°C
Uncertainty includes long-term stability of 1yr (5yrs for frequency),
temperature coefficient, linearity, load and line regulation and the
traceability of factory and National calibration standards. In general,
nothing further needs to be added to determine the Test Uncertainty
Ratio over the instrument under calibration.
9500B Base Unit 95xx Active Heads
Dimensions: H x W x D H x W x D
133 x 427 x 440 mm 65 x 29 x 140 mm
5.24 x 16.8 x 17.3 ins 2.56 x 1.22 x 5.51 ins
Weight: 12 kg (27 lbs) 0.45 kg (1 lb) .
approx. approx
Warranty Period: 1-year 3-year Active Plus
CarePlan
7.1.1 Environmental
Environmental Operating Storage
Temperature: 5˚C to 40˚C 0˚C to 50˚C
Transit <100hrs
-20˚C to 60˚C
Humidity: <90% 5˚C to 30˚C <95% 0˚C to 50˚C
(non-condensing) <75% 30˚C to 40˚C
Water Ingress IP65
Altitude: <2000m, 6500ft <12000m, 40000ft
Safety Designed to and documented to
EN61010-1-1:1993/A2:1995.
CE and ETL marked
EMC (including options)
Radiated Emissions EN55011/22
FCC Rules
part 15 sub-part J class B
Radiated Immunity EN50082-1
Conducted Emissions EN55011 1991 Class B
Conducted Immunity EN50082-1
Harmonics EN61000-3-2
Shock and Vibration MIL-T-28800 type III
class 5, style E.
Pollution Degree 2
Line Voltage 95V to 132V rms
209V to 264V rms
Installation Cat II
Line Frequency 48Hz to 63Hz
Power Consumption <400 VA
Line Fuse: 220/240V T5.0A 250V
20mm IEC127 100/120V T10.0A 250V
Warm-up: 20 minutes
7.1.2 Dimensions
