7-6 Section 7: Model 9500B — Specifications
Final Width = 215mm
7.7 Dual Sine Function Specification
9500B/600 9500B/1100 9500B/3200 & 9530 9500B/3200 & 9560
Frequency Range: 0.1 Hz to 600 MHz 0.1 Hz to 1.1 GHz 0.1 Hz to 3.2 GHz 0.1 Hz to 3.2 GHz
Time Alignment: ±25ps Any Channel to Any Channel
Amplitude (pk-pk): 0.1Hz to 550MHz: 0.1Hz to 550MHz: 0.1Hz to 550MHz: 0.1Hz to 550MHz:
(into 50Ω) 5mV to 2.5V 5mV to 2.5V 5mV to 2.5V 5mV to 2.5V
550MHz to 600MHz: 550MHz to 1.1GHz: 550MHz to 2.5GHz: 550MHz to 2.5GHz:
5mV to 1.5V 5mV to 1.5V 5mV to 1.5V 5mV to 1.5V
2.5GHz to 3.2GHz: 2.5GHz to 3.2GHz:
5mV to 1V 5mV to 1V
Accuracy and Flatness: As Levelled Sine above
(Master Channel)
Flatness wrt Ref Freq: 0.1Hz to 600MHz: 0.1Hz to 750MHz: 0.1Hz to 750MHz: 0.1Hz to 1GHz:
(Slave Channel) ±10% ±10% ±10% ±10%
750MHz to 1.1GHz: 750MHz to 1.1GHz: 1GHz to 3.2GHz:
±30% ±30% ±25%
Frequencies above 500MHz are not recommended for 1MΩ input applications.
The 9560 Head is restricted to 50Ω loads only.
7.7.2 Input Impedance Functions (Not available via 9550 Active Head)
Resistance Measurement: 10
Ω - 40Ω 40Ω - 90Ω 90Ω - 150Ω 50kΩ - 800kΩ 800kΩ - 1.2MΩ 1.2MΩ - 12MΩ
Accuracy: ±0.5% ±0.1% ±0.5% ±0.5% ±0.1% ±0.5%
(Not available via 9550 or 9560 Active Head)
Capacitance Measurement: 1pF to 35pF 35pF to 95pF
Accuracy: ±2% ±0.25pF ±3% ±0.25pF
7.7.1 Levelled Sine Function (Selected heads must be of the same type, either 9510, 9530 or 9560
